42R Series AC Induction Motor
Model 0260
SPECIFICATIONS
| Speed (rpm) | 1700 |
| Rated Torque (oz-in) | 101 |
| Motor HP | 1/6 |
| Voltage | 115 |
| Hz | 60 |
| Phases | 1 |
| Amps | 1.9 |
| Radial Load (lbs) | 50 |
| Length XH (inch) | 6.7 |
| Weight (lbs) | 11 |
| Connection Diagram | 07410296 |
| Capacitor Part Number | 49401075 |
| Product Type | 42R5BFCI |
| Mounting | NEMA C |
| HPDecimal | 0.1667 |
CAD Drawings
Wiring Diagram
Optional Accessories
Die cast terminal box kit for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 0984]
Die cast metric terminal box kit with terminal block for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 1984]
Large die cast terminal box kit for 34R, 42R, 48R, 42R-FX, 33A, 42A stock motors and gearmotors [model 0986]
STANDARD FEATURES
- Totally enclosed IP-20 rating.
- Fan cooled for high output power.
- Aluminum center ring and end shields for high thermal efficiency and light weight.
- Permanently lubricated, noise tested ball bearings.
- Locked bearing design minimizes shaft endplay.
Ready to Purchase? Find a Distributor
All prices are in U.S. dollars. Specifications and prices are subject to change without notice. Web price excludes taxes, shipping, and handling charges. Terms & Conditions of Sale
Availability
Order Quantity: 1-25
Chat with us for Current Stock Availability
-
Die cast terminal box kit for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 0984]View
![Die cast terminal box kit for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 0984]](https://www.bodine-electric.com/core/files/bodineelectric/cart/9dae24061421d55b465c7bc0f275be43.jpg)
-
Die cast metric terminal box kit with terminal block for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 1984]View
![Die cast metric terminal box kit with terminal block for 33A, 34R, 42A, 42R, and 48R motors and gearmotors [model 1984]](https://www.bodine-electric.com/core/files/bodineelectric/cart/0808f20850ded77924349c98e43375fb.jpg)
-
Capacitor; plastic box type; 15.0 MFD / 350V [Item 49401075]View
